Main characteristics
- For indoor or outdoor applications
- Power up to 2,5-16 MVA and rating voltage up to 66 kV
- Frequency 50/60 Hz
- With normal or low level losses
- Cooling system: ONAN
- With conservator tank or hermetical sealed
- Ground pad or poll mounted
- Standards: IEC 60076, ANSI C57
- With normal or low noise level
Customer benefits
- Low level losses
- Low costs operating and maintenance
- Short delivery time
- Rapid installation
| TYPE | RATED OUTPUT (KVA) | VOLTAGE (KV) | VOLTAGE CONTROL (%) | VECTOR GROUP | PCS. | YEAR of DELIVERY | APPLI - CABLE STD | COUNTRY | CUSTOMER |
|---|---|---|---|---|---|---|---|---|---|
| TTU ONAN | 10000 | 20/6,3 | ±2 x 2,5 | Dd0 | 1 | 2011 | IEC | ROMANIA | ED ENGINEERING IMPEX |
| TTU- ONAN | 8000 | 135/6.6 | ±2x5 | YNyn0 | 1 | 2009 | IEC | IRAQ | URNASHA |
| TTU-ONAN | 6000 | 33/3.45 | ±2x2,5 | Dy1 | 2 | 2008 | IEC | IRAQ | BLACK SEA- DUBAI |
| TTU-ONAN | 3000 | 36/90 | N/A | YNd11 | 1 | 2008 | IEC | DENMARK | BURKINA FASO |
| TTU-ONAN | 2000 | 33/0.415 | ±2x2,5 | Dy11 | 5 | 2008 | IEC | IRAQ | BLACK SEA- DUBAI |
| TTU-ONAN/ONAF | 16000 | 6,3/15-20 | ±2x2,5 | Ynd11 | 1 | 2007 | IEC | GREECE | PPC |
| TTU-ONAN/ONAF | 8000 | 6,3/15-20 | ±2x2,5 | Ynd11 | 1 | 2007 | IEC | GREECE | PPC |
| TTU- ONAN | 1250 | 13,8/0,48 | ±2x2,5 | Dd0 | 1 | 2007 | IEC | DENMARK | BWSC |
| TTU- ONAN | 1200 | 2,4/0,48 | ±2x2,5 | Dd0 | 1 | 2007 | IEC | DENMARK | BWSC |
| TTU-ONAN | 5500 | 11,5/20 | ±2x2,5 | Dyn1 | 1 | 2006 | IEC | GREECE | HERON |
| TTU-ONAN | 3000 | 15/0,5 | ±2x2,5 | Dyn11 | 1 | 2006 | IEC | GREECE | HERACLES |
| TTU- ONAN | 3000 | 132/6 | ±2x2,5 | Dyn1 | 1 | 2006 | IEC | MAROCO | SMTE |
| TTU-ONAN | 2000 | 15/2,3 | ±2x2,5 | Dyn11 | 1 | 2006 | IEC | GREECE | HERACLES |
| TTU-ONAN | 3350 | 6.3/0.65 | ±2x2.5 | Dyn-5 | 1 | 1993 | IEC | CHINA | PUCHENG P/P |
| TTU-ONAN | 5000/6500 | 69/13.8 | 1X12.5; -4x2.5 | Dy-1 | 5 | 1991 | ABND | BRAZIL | CEPISA S/S |
| TTU-ONAN | 5000/6250 | 69/34.5 | 1X2.5; -4x2.5 | Dy-1 | 6 | 1991 | ABND | BRAZIL | CERON S/S |
| TTU-ONAN | 3000 | 34.5/13.2 | ±2x2.5 | Dy-11 | 15 | 1991 | ABND | BRAZIL | LIGHT S/S |
| TTU-ONAN | 5000 | 69/13.8 | 1x2.5; -4x2.5 | Dy-1 | 6 | 1991 | ABND | BRAZIL | CEMAR S/S |
| TTU-ONAN | 6300 | 35/6.3 | ±2x2.5 | YNd-11 | 2 | 1990 | IEC | CHINA | CAO CUN MI |
| TTU-ONAN | 6300 | 132/11.5 | ±4x2.5 | YNzn-11 | 2 | 1990 | BS | PAKISTAN | WAPDA 407 |
| TTU-ONAN | 6300 | 66/11.5 | ±4x2.5 | YNzn-11 | 4 | 1989 | BS | PAKISTAN | WAPDA 407 |
| TTU-ONAN | 5000/6250 | 66/13.8 | 2x2.5; -3x2.5 | Dyn-1 | 4 | 1988 | ABND | BRAZIL | COELCE S/S |
| TTU-ONAF | 5000/6250 | 69/13.8 | 2x2.5; -3x2.5 | Dyn-1 | 1 | 1988 | ABND | BRAZIL | COELCE S/S |
| TTU-ONAF | 12500/15000 | 39/13.8 | ±2x2.5 | Dyn-1 | 4 | 1988 | ABND | BRAZIL | CELPA S/S |
| TTU-ON AF | 10000/12500 | 66/13.8 | 2x2.5; -2x2.5 | Dyn-1 | 2 | 1988 | ABND | BRAZIL | COSERN S/S |
